JBL BAR 9.1 True Wireless Surround with Dolby Atmos®

Details
Variations

9.1 Channel Soundbar System with surround speakers and Dolby Atmos®



Feel like you're right in the scene with 3D surround sound

The JBL Bar 9.1 soundbar brings audio experience of a movie theater into your home with two detachable surround speakers and the added punch of Dolby Atmos® and DTS:X™ 3D sound. With 820 watts of total system power, you can enjoy every Oscar-worthy performance through powerful, crystal-clear audio. Turn up the 10’’ subwoofer for pulse-pounding bass or turn it down and relax with Chromecast and AirPlay music streaming. Immerse yourself in the latest blockbuster or re-live your favorite movie or sport scenes. The most incredible home cinema sound experience is here.

Item# JBLBAR913DBLKAS

General Specifications

5.1.4 channel Yes
Power supply 100 - 240VAC, ~ 50/60Hz
Battery charge time 3 hours
Total speaker power output (Max. @THD 1%) 820 W
Main Soundbar output power (Max. @THD 1%) 400
Surround speakers output power (Max. @THD 1%); 2 x 60W Yes
Subwoofer output power (Max. @THD 1%); 300 Yes
Soundbar transducer 4×racetrack drivers + 2 × up-firing full-range drivers+3 × 0.75” (20mm) tweeter
Surround transducer (per piece) up-firing full-range driver + 0.75” (20mm) tweeter
Subwoofer transducer 10"
Operating temperature 0°C - 45°C
Standby for Soundbar (when all wireless connections are deactivated) < 0.5 W
Networked standby (Soundbar) < 6.0 W
Networked standby (Subwoofer) < 2.0 W
Time to standby <10 minutes
This equipment complies with European Commission Regulation (EC) No 1275/2008 and (EU) No 801/2013. The Soundbar unit is considered as networked equipment with high network availability (HiNA equipment and equipment with HiNA functionality) as it provides wireless network access point for two wireless Surround speakers and one wireless Subwoofer. Yes

Audio Specifications

HDMI In 1
HDMI eARC 1
HDMI HDCP version 2.3
103dB Yes
34Hz~20KHz Yes
1 Optical, Bluetooth, Chromecast, AirPlay2, USB Yes

Dimensions

Soundbar dimensions (WxHxD); 884 x 62 x 120 (mm)/ 34.8” x 2.4” x 4.7” Yes
Detachable surround speaker, per piece 173 x 60 x 120 (mm) / 6.8” x 2.4” x 4.7”
Subwoofer dimensions (WxHxD); 305 x 440 x 305(mm) / 12.0" x 17.3" x 12.0" Yes
Soundbar weight 3.64 kg/ 8.0 lb
Detachable surround speaker 0.72 kg x 2/ 1.6 lb x2
Subwoofer weight 11.10 kg / 24.5 lb

Control and Connection Specifications

USB port Type A
USB rating 5 V/ 500 mA
Supported file format MP3
MP3 codec MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate; 16 KHz - 48 KHz Yes
MP3 bitrate 80 kbps - 320 kbps
USB Port; (USB playback is available in US version. For other versions, USB is for Service only.) Yes
Bluetooth version 4.2
Bluetooth profile A2DP V1.2/ AVRCP V1.5
Bluetooth frequency range; 2402MHz-2480MHz Yes
Bluetooth Max. transmitting power 13dbm  (EIRP)
Modulation Type GFSK, π/4 DQPSK, 8DPSK
Wi-Fi network IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi frequency range 2412 – 2472 MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi Max. transmitting power 20 dBm (EIRP)
Modulation Type DBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM
5G Wi-Fi frequency range 5.15 - 5.35 GHz, 5.470-5.725 GHz, 5.725 - 5.825 GHz
5G Wi-Fi Max. transmitting power 22 dBm (EIRP)
Modulation Type QPSK, BPSK, 16QAM, 64QAM, 256QAM
5G Wireless frequency range 5180.0 - 5240.0MHz (Except Europe), 5725.0 - 5825.0MHz
5G Max. transmitting power 13 dBm (EIRP)
Modulation Type QPSK
Click here for a complete list of all specs for this product

Spec Sheet (English)

English 623 KB
  • 1x Main Soundbar
  • 2x Detachable wireless surround speakers
  • 1x Wireless subwoofer
  • Remote control with 2 x batteries
  • Power cords (up to 8pcs depending on region SKUs)
  • HDMI cable x1
  • 2 x L-shape Wall-mount bracket (Main Bar) + 2 x U-shape Wall-mount bracket (for Surround Speakers) kit with screws
  • Quick start guide
  • Warranty card
  • Safety sheet
product box
